FLIR IM75-2 Insulation Multimeter

The FLIR IM75-2 is both an advanced multifunction digital multimeter and a premier handheld insulation tester with functions for installation, troubleshooting and maintenance for professionals. The FLIR IM75-2 includes several specialty insulation modes such as polarization index, dielectric absorption, and earth bond resistance. Insulation tests can be performed instantly, continuously, and over a timed duration to allow for in-depth assessment. The multi-color LED indicator in compare mode makes pass/fail determinations easy and visible. Use the METERLiNK® app to quickly and efficiently capture readings, images, and videos for analysis, trending, and sharing.Advanced Insulation Testing• Advanced multifunction digital multimeter and premier handheld insulation tester for installation, troubleshooting and maintenance professionals • Insulation voltage testing up to 1 kV, measuring insulation resistance from 4 MΩ to 20 GΩ • Advanced variable frequency drive (VFD) filtering and dual display shows voltage and frequency at once • True RMS DMM measurements features reliable performance and 1000 V rangeBuilt Tough for Demanding Work Conditions• Constructed to make any electrical problem easier to troubleshoot • Powerful LED worklights eliminate the need for a flashlight in dim lighting • Durable, double-molded construction with IP54 rating and 3 m drop tested • Large, easy-to-read digits and backlit display • Multi-color LED indicator with Compare Mode makes pass/fail determinations easy and visibleApp Connectivity to Support Your Workflow• Wireless communication with the FLIR METERLiNK® App • Capture readings, create reports and easily share them with your team • Perform measurement comparisons over time • Set custom alarm thresholds to provide additional assurance of operating ranges while performing testing proceduresGET INSPECTION EQUIPMENT TO THE PEOPLE YOU NEEDFLIR METERLiNK® AppThe FLIR METERLiNK® app allows you to monitor a variety of environmental and electrical conditions simultaneously with the ability to connect with up to seven FLIR compatible meters at once. METERLiNK allows you to safely capture images and monitor hazardous areas remotely and in real time. Whether you’re connecting several FLIR clamp meters, digital multimeters, or any of the new METERLiNK app compatible meters, you will be able to keep tabs on key readings around your facility and easily share them with your team.Warranty Information10-Year limited manufacturer warranty with registration. Great Lakes Gages provides ongoing calibration services and technical support for the life of the tool.SpecificationsInsulation Resistance4.000 MΩ ± (1.5% 5 digits) 40.00 MΩ ± (1.5% 5 digits) 400.0 MΩ ± (3.0% 5 digits) 4000 MΩ ± (3.0% 5 digits) 4.1 G to 20.0 GΩ ± (10.0% 3 digits)Insulation Test Voltages50 V for max. 50.0 MΩ 100 V for max 100.0 MΩ 250 V for max. 250.0 MΩ 500 V for max. 500.0 MΩ 1000 V for max.20 GΩCategory RatingCAT IV-600 V, CAT III-1000 VMeasurement & AnalysisAC Voltage1000.0 V: 50 Hz to 60 Hz ± (1.5% 5 digits), 61 Hz to 500 Hz ± (2.0% 5 digits)Capacitance1000 µF ± (1.2% 2 digits) 10.00 mF ± (1.2% 20 digits)Category RatingCAT IV-600 V, CAT III-1000 VContinuity400.0 Ω ± (0.5% 2 digits)DC Voltage1000.0 V ± (0.1% 5 digits)Earth Bond Resistance40.00 Ω ± (1.5% 5 digits) 400.0 Ω ± (1.5% 3 digits) 4000 Ω ± (1.5% 3 digits) 40.00 kΩ ± (1.5% 3 digits)Frequency [ACV]400.0 Hz ± 5 digits 4.000 kHz ± 5 digits 40.00 kHz ± 5 digitsInsulation Resistance4.000 MΩ ± (1.5% 5 digits) 40.00 MΩ ± (1.5% 5 digits) 400.0 MΩ ± (3.0% 5 digits) 4000 MΩ ± (3.0% 5 digits) 4.1 G to 20.0 GΩ ± (10.0% 3 digits)Insulation Test Voltages50 V for max. 50.0 MΩ 100 V for max 100.0 MΩ 250 V for max. 250.0 MΩ 500 V for max. 500.0 MΩ 1000 V for max.20 GΩVFD AC Voltage1000.0 V: 50 Hz to 60 Hz ± (1.5% 5 digits), 61 Hz to 400 Hz, ± (5.0% 5 digits)Communication & Data StorageBluetooth range max10 m (32 ft)Memory99 storage locationsPowerBattery Type6 × 1.5 V AAA alkaline batteriesEnvironmental & CertificationsCertificationsFCC Class B, CE, UL, UKCA, RCMDrop test3 m (9.8 ft)IP RatingIP54 dust-protected and splash-resistantOperating Temperature0°C to 50°C (32°F to 122°F)Warrantyhttps://www.flir.com/testwarranty  SKU: N/A Category: Insulation Multimeter Tag: FLIR
